Truecharge Battery Charger 12VDC 20A

Model: TRUECHARGE2-20 (804-1220-02)

Input 90-265VAC, 47-63Hz
Output 12VDC, 20A
Dimensions 2.8"H x 6.7"W x 9.8"L, Approx. Shipping Weight 8 lbs

Product Overview:
Xantrex TRUECharge Battery Charger leads the industry with a small footprint and ultra-compact design. Designed for commercial applications worldwide the TRUECharge features an input voltage of 90 Vac to 265 VAC, 47 to 63 Hz, which can be used in most parts of the world.

Standard Features:
  • Available in 10, 20, 40 & 60 Amp
  • Auto-ranging universal input voltage of 90-265 VAC, 47-63 Hz
  • Low electrical interference and efficient
  • Power factor corrected multistage charging.
  • Inherent drip-proof design characteristics for multiple mounting positions.
  • Built-in protection against surges and spikes on the AC power line.
  • Settings for flooded, gel, AGM or lead-calcium batteries
  • Ability to charge batteries drained to extremely low voltage
  • Easy access to AC and DC wiring from one side
  • Tested to conform to ingress protection rating IP32 and meets UL1564, UL1236 including marine supplement and ABYC standards
  • Optional Remote Panel
  • Optional Battery Temperature Sensor

Technical Support Call: 1-800-670-0707

Model Input Voltage VAC Output Voltage VDC Output Power Availability Quantity
TRUECHARGE2-20 (804-1220-02) 90-265VAC 12VDC 20 Amps Request Lead time
  • $356.00
TRUECHARGE2-40 (804-1240-02) 90-265VAC 12VDC 40 Amps In stock
  • $432.00
TRUECHARGE2-60 (804-1260-02) 90-265VAC 12VDC 60 Amps In stock
  • $753.00
TRUECHARGE2-10/24 (804-2410) 90-265VAC 24VDC 10 Amps In stock
  • $417.00
TRUECHARGE2-20/24 (804-2420) 90-265VAC 24VDC 20 Amps In stock
  • $525.00
TRUECHARGE2-30/24 (804-2430) 90-265VAC 24VDC 30 Amps In stock
  • $753.00


Battery Temp Sensor
  • $40.00
TrueCharge2 Remote Panel
  • $100.00
