Rackmount DC-DC Converter 24VDC to 48VDC 8A

Input 20-30 VDC @ 26 Amps
Output 54.4 VDC @ 8 Amps Continuous
Dimensions 3.5"H x 19/23"W x 14"D, Weight 10 lbs

Product Overview
Isolated Rackmount DC/DC Converter for communication sites that provides excellent voltage regulation, low noise, and high efficiency voltage conversion. Reliable under continuous duty operation and high ambient temperatures.

Standard Features :

• 48, 24 volt inputs; 12, 24 volt outputs; positive, negative or floating ground
• Input/Output chassis isolation – 250 VDC
• 400 watt output
• Rated for continuous duty at full load
• Excellent regulation under all line/load conditions
• Low ripple provides noise free output
• High efficiency – 87% typical
• Easily adapts to both 19" and 23" racks, center mount (6" from front)
• Output volt and ammeter
• Output voltage adjustment on front panel
• Low profile – occupies two RU (one RU space above and below recommended for cooling)
